| Models | Unit | PTHT |
| Communication Function | – | NC |
| Temperature Adjustment Range | °C | 0-60 |
| Potentiometer Color | – | Red |
| 250V AC / 120V AC | A | 10 (2) |
| Sensor Type | – | Bimetal |
| Contact Type | – | Sudden movement |
| Service Life | Cycles | > 100.000 |
| Electrical Connections | – | 2-Pole terminal block |
| Plastic Material | – | UL94 V0 ABS Flame Retardant |
| Degree of Protection | EN60529 | IP20 |
| Operating Temperature | °C | -25 / +80 |
| Storage Temperature | °C | -45 / +80 |
| Assembly | – | 35 mm must be mounted on the DIN rail |
| Dimensions HxWxD | mm | 61x34x38 |
| Weight | g | 45 |
