| Features | MPHT 15 | MPHT 25 |
| Heating Capacity | 15 | 25 |
| Feeding | 100-250V AC DC | 100-250V AC DC |
| Maximum Current | 2A | 2A |
| Heating element type | PTC Heater | PTC Heater |
| Overcurrent protection | Electronic thermal relay | Electronic thermal relay |
| Electrical connections | 30 cm L-N-E with cable | 30 cm L-N-E with cable |
| Protection Class IEC | Class II | Class II |
| Degree of Protection EN60529 | IP20 | IP20 |
| Operating Temperature | -45 / +70 °C | -45 / +70 °C |
| Storage Temperature | -45 / +70 °C | -45 / +70 °C |
| Body | Anodized aluminum profile | Anodized aluminum profile |
| Assembly | 35 mm DIN rail plug-in | 35 mm DIN rail plug-in |
| Mounting Position | Vertical position for best efficiency | Vertical position for best efficiency |
| Dimensions HxWxD | 60x50x27 mm | 70x50x27 mm |
| Weight | 0.11 kg | 0.12 kg |
