| Models | Unit | PTS4000 | PTS5500 | PTS6000 |
| Capacity | m3/h | 400 | 560 | 970 |
| Power Supply | V/Hz | 230V 50-60Hz | 230V 50-60Hz | 230V 50-60Hz |
| Dimensions | mm | 364x364x107 | 364x364x107 | 364x364x107 |
| Power Consumption | W | 25/32 | 58/75 | 85/90 |
| Instant Consumption | A | 0.11/0.15 | 0.26/0.34 | 0.38/0.44 |
| Current Protection | - | Thermal | Thermal | Thermal |
| Electricity Connection | - | 3-Pole Terminal Block 2.5mm² | 3-Pole Terminal Block 2.5mm² | 3-Pole Terminal Block 2.5mm² |
| Operating Temperature | C | -10/+70 | -10+70 | -10/+70 |
| Degree of Protection | - | IP54 | IP54 | IP54 |
| Noise Level | dB(A) | 62 (64) | 62 (64) | 72 (73) |
| Flow Direction | - | Inside Out | Inside Out | Inside Out |
| Shaft Bearing | - | Global | Global | Global |
| Service Life | Clock | 50.000 | 50.000 | 50.000 |
| Plastic Material | - | UL94 V0 ABS Flame Retardant | UL94 V0 ABS Flame Retardant | UL94 V0 ABS Flame Retardant |
| Gasket | - | Polyurethane Bulk | Polyurethane Bulk | Polyurethane Bulk |
| Weight | kg | 2,60 | 3,16 | 3,74 |
| Connection | - | Fast assembly without screws | Fast assembly without screws | Fast assembly without screws |
